Fast, Powerful Charging
An operator-ready dual-connector DC fast charger with Plug & Charge, rich user displays, and >96.8% energy efficiency for quick-turnaround sites.
1
2
3
4
5
6
21.5" Advertising Display
Plug & Charge
(ISO 15118)
RFID Authentication
Clean Cable Management
Wide Range of Payment Options
Dynamic Power Distribution
- Input Rating
- 380 VAC±10%, L1+L2+L3+N+PE
- Power Factor
- >0.99
- Efficiency
- >96.8%
- Power Output
- 180 kW (Max)
- DC Output Control
- Dynamic Output
- DC Output Voltage
- 150–1,000 V DC
- DC Output Current
- 300 A (max)
- Charging Connectors
- 2 Connectors (CCS1 + CCS2), bottom cable entry
- Electrical Protection
- OVP, OCP, OPP, OTP, UCP, UVP, SPD
- Certification
- VPC
CNS 15511-23 ; CNS 15511-24 ; CNS15511-21-2 ; CNS15511-1
- Display and Button
- 10.1" LCD Screen (Supports Traditional Chinese and English Interfaces) 21.5" LCD Advertising Screen (Optional) Emergency button; LED indicator
- Support Language
- English, Traditional Chinese
- Authentication
- QR code (MSI-qConnect)
- Network
- Ethernet
- OCPP Support
- OCPP 1.6J
- Operating Temp.
- −30 °C to 50 °C
- Humidity
- 5%–95% (non-condensing)
- Ingress Protection
- IP55
- Enclosure Protection
- IK08
- Cooling
- Forced air
- Installation
- Ground Install
- Charging Cable Length
- 5m
- Dimensions
- With Cable Management System: 1996 × 800 × 495 mm / 78.58 × 31.50 × 19.49 in (Optional)
Without Cable Management System: 1800 × 800 × 495 mm / 70.87 × 31.50 × 19.49 in - Weight
- 360 kg / 795 lbs
- Standards and Protocol
- ISO15118-1-2013; ISO15118-2-2014; ISO15118-3:2015; DIN 70121-2014
Fast & Flexible Charging
180 kW dual-connector simultaneous charging with dynamic power sharing. Intelligent distribution of power maximises station throughput and minimizes wait time for drivers.
Station Owner Benefits
Turn chargers into revenue and reduce downtime. The Hyper 180 Dual is OCPP 1.6J compatible with operator back-ends for station management, payment gateway connections (QR code/RFID card), and remote diagnostics. It enables monetisation, uptime monitoring, and simplified maintenance at scale.
Modular and Operator-Friendly
Robust cable management, emergency stop, and a modular power architecture for fast field repairs. The Hyper 180 Dual features a rear service cabinet with hot-swap power modules for quick maintenance and high uptime.
Commercial Site Management with eConnect
The eConnect cloud-native commercial charging platform makes large or multi-site deployments simple to operate and profitable to run. It centralises station monitoring, billing, and policy controls to keep ports online, monetise sessions, and scale without adding complexity.
Learn More
